TOOLS FOR INSTALLING SMART GLASS FILM IN ADHESIVE WAY
BY PETER SHIN LIN WWW.CNCNEXT.COM WWW.HELLOGLASS.COM
Scraper:to clean glass before installing smart
glass film
Glove: to protect hands
All rights reserved by CNC INTERLAYER TECH www.cncnext.com Ethanol(70- 90%): to clean glass, smart film and
over flow SUNLIGHT glue
Lint Free Clean Tissue: to clean windows and
smart glass film
Lint Free Cloth: to clean windows and smart
glass film
All rights reserved by CNC INTERLAYER TECH www.cncnext.com Transparent Tape: to seal smart film onto
windows
Fabric Tape: to pick up dust if necessary
Special SUNLIGHT Glue: to adhere smart glass
film
All rights reserved by CNC INTERLAYER TECH www.cncnext.com Dropper: to drop SUNLIGHT glue
Soft Roller:to roll the smart glass film onto
windows
UV Light: to solidify the SUNLIGHT glue faster
All rights reserved by CNC INTERLAYER TECH www.cncnext.com Iusulating Tape: to cover wire and busbar
Power Device&Remote: to adjust the voltage for
smart glass film, and control smart glass film
All rights reserved by CNC-INTERLAYER TECH:
【1】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS 【2】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS
【3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS Web: www.CNCnext.com
Mail: [email protected]
[email protected]/
[email protected]
All rights reserved by CNC INTERLAYER TECH www.cncnext.com

Tools for Installing Self-Adhesive Smart Glass Film.pdf

Re-Cut Size of Smart Glass Film After Busbar Installed
BY PETER SHIN LIN WWW.CNCNEXT.COM WWW.HELLOGLASS.COM
It’s better if you don’t put yourself in this situation, so please double make sure that you have correct size of the smart glass film you need before the busbar is installed
Open the tape slightly
Open the tape slightly
Open the tape slightly
Open the copper slightly
Open the copper slightly
Open the copper slightly
Cut the extra size of smart glass film without cuting the copper Reinstall the copper
Reinstall the copper
Reinstall the tape
“SMART GLASS FILM is composed by two transparent conductive film laminating with a polymer liquid core. And the polymer liquid core composes crystal ball and polymer. When the light pass through the SMART GLASS FILM and reach the liquid crystal ball and polymer, the light is scattering. And the SMART GLASS FILM appears translucent. When electricity power is connected, the polymer-liquid crystal core is allowing light pass through, the SMART GLASS FILM appears transparent.”
“All rights reserved by CNC-INTERLAYER TECH:
【1】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS 【2】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS
【3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS Web: www.CNCnext.com
Mail: [email protected]
[email protected]/
[email protected]”
Re-Cut Size of Smart Glass Film After Busbar Installed.pdf

HOWTO OPERATE POWER DEVICE AND REMOTE OF SMART GLASS PRIVACY FILM BY PETER SHIN LIN WWW.CNCNEXT.COM WWW.HELLOGLASS.COM
It’s easy to operate the power device and remote of smart glass film, but if it’s your first time, please pay attention to some notes. Connecting to the electricity , and press the red button
You will see the green light is on, which means the power
connection is correct
Put the battery onto the remote, we can not send the battery with the remote when delivering by DHL, so you have to buy it in your country
Put the battery onto the remote
Then you see the light is not on
When you press the ON button, the light will be on, which means the remote is working well
When you press the OFF button, the light will be on, which means the remote is working well
“SMART GLASS FILM is composed by two transparent conductive film laminating with a polymer liquid core. And the polymer liquid core composes crystal ball and polymer. When the light pass through the SMART GLASS FILM and reach the liquid crystal ball and polymer, the light is scattering. And the SMART GLASS FILM appears translucent. When electricity power is connected, the polymer-liquid crystal core is allowing light pass through, the SMART GLASS FILM appears transparent.”
“All rights reserved by CNC-INTERLAYER TECH:
【1】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS 【2】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS
【3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS Web: www.CNCnext.com
Mail: [email protected]
[email protected]/
[email protected]”

HOWTO OPERATE POWER DEVICE AND REMOTE OF SMART GLASS PRIVACY FILM.pdf

HOWTO INSTALL BUSBAR OF SMART GLASS PRIVACY FILM
WWW.CNCNEXT.COM WWW.HELLOGLASS.COM Peter Shin
You can DIY the busbar by yourself, following is instruction. If you have doubts, please feel free to contact us. [email protected] Cut a piece out of one angle of UP side of smart film.(The length of the cut is about 30% of the smart glass film)
Cut a piece out of one angle of UP side of smart glass film Cut PET out of one angle of DOWN side of smart glass film
Use the ethanol to wash the cuts in both side
Use the ethanol to wash the cuts in both side
Use ethanol to wash the cuts in both side of smart glass film until it is clean
Pepare the conductive glue (if it’s too dense, you can use 99% ethanol to dilute conductive glue)
Draw conductive glue onto the cut on both sides of smart glass film. Make sure the conductive glue not touch the un-cut smart film edges Draw conductive glue onto the cut
Draw conductive glue onto the cut
Draw conductive glue onto the cut. Make sure the conductive glue not touch the UNCUT smart glass film edges
Use dryer to dry the conductive glue
Put the copper tape onto the conductive glue
Put the copper tape onto the conductive glue
Put the copper tape onto the conductive glue
Put the copper tape onto the conductive glue, make sure the copper of one side is longer to be bent on to the other sizde, so we can soldering both electrodes on same side
Put the copper tape onto the conductive glue, make sure the copper of one side is longer to be bent on to the other sizde, so we can soldering both electrodes on same side
Put the copper tape onto the conductive glue, make sure one copper of one side is longer to be bent on to the other sizde, so we can soldering both electrodes on same side
Soldering both electrodes on same side
Use insulating tape to seal the busbar
Use insulating tape to seal the busbar
Connecting with power device and turn on the switch, you will see the smart film is transparent
“Turn off the switch, you will see the smart film is frosted. Now you have finished installing the busbar of smart glass film. Congratulations！

If you have doubts, pleae feel free to contact Peter at this Email address: [email protected]”
“SMART GLASS FILM is composed by two transparent conductive film laminating with a polymer liquid core. And the polymer liquid core composes crystal ball and polymer. When the light pass through the SMART GLASS FILM and reach the liquid crystal ball and polymer, the light is scattering. And the SMART GLASS FILM appears translucent. When electricity power is connected, the polymer-liquid crystal core is allowing light pass through, the SMART GLASS FILM appears transparent.”
“All rights reserved by CNC-INTERLAYER TECH:
【1】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS
【2】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS 【3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS Web: www.CNCnext.com
Mail: [email protected]
[email protected]/
[email protected]”
HOWTO INSTALL BUSBAR OF SMART GLASS PRIVACY FILM.pdf

Install Smart Glass Film to Fixed Windows in Self-Adhesive WayWith Sunlight Glue By Peter Shin www.HelloGlass.com
Please remember to read the notes in the end of the document. 1.
Tools and materials:
Scraper, glove, clean tissue, ethanol(70%-90%), SUNLIGHT glue, Burette, Soft roll. (We can supply whole set tools for you.)

2.
Use black plastic film/cloth to cover the other size of windows to make the SUNLIGHT glue for smart glass film not solidify too fast.

3.
Hang the smart glass film onto window.

4.
Use rubber roller to roll smart glass film onto window to check the dust on the window surface.

5.
Double check there is no dust on the window surface.

6.
Lift the smart film carefully to clean dust.

7.
Use transparent tape to seal the right side, left side and down side of the smart glass film to make a “bag”.

8.
Drop Sunlight glue at the top into the “bag”.

9.
Sunlight glue will go down by itself.

10.
Use rubber roller to roll the smart film from down to up to disperse the Sunlight glue.

11.
Roll softly and slowly to avoid the bubbles.

12.
No matter whether there is bubbles left or not, please double roll the smart film to make sure the glue is well partitioned. At this time, please roll the smart glass film from center to edges.

13.
Use a pair of magnet to adjust the place where the Sunlight Glue is still not well partitioned.

14.
Use ethanol to clean the smart glass film.

15.
The Sunlight glue will solidify by itself.

16.
The installation of smart glass film in self-adhesive way is done.

Notes of Installation of the Smart Glass Film:
1.
The special SUNLIGHT Glue only require sunlight to solidify. 2.
Before the the SUNLIGHT Glue is solidified, you can re-do the procedure to clean dust or eliminate bubbles if you find them after installation.
3.
The solidifying may finish in several minutes in great sunlight or takes a day in the indoor environment, So if you need long time to install smart glass(Suppose it’s your first time), you can use a black paper to cover the other side of the window to avoid the sunlight.

All rights reserved by CNC-INTERLAYER TECH:
【Product 1】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS 【Product 2】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS 【Product 3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS Web: www.CNCnext.com www.HelloGlass.com
Mail: [email protected]
[email protected]/
[email protected]

THE ADVANTAGES OF CNC SMART GLASS FILM (PRIVACY FILM, PDLC FILM, SPD FILM)

www.evafilms.com www.HelloGlass.com

-Best optics properties. Light transmittance of smart glass film is highest when power is on.

-Low voltage needed. The lower voltage, the safer to use smart glass film.

-Good at humidity resistance, Thermal resistance, and UV radiation resistance.. The smart glass film can be used in exterior environment.

-Best projection effect. The view angle independence is very wide.

-Save energy, green life.

-Prolonged product life. The life of switching of smart glass film is highly modified.

All rights reserved by CNC-INTERLAYER TECH:

【Product 1】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS

【Product 2】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS

【Product 3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS

Web: www.CNCnext.com www.HelloGlass.com

Mail: [email protected]

[email protected]/

[email protected]

10 Function Characteristics of Smart Glass Film You Should Know By Peter Shin
www.EVAfilms.com / www.CNCnext.com

1.
Brightness stability
Variable brightness individual. At any angles, the brightness of projection is the same due to utilizing non-linear technology and nano-technology.
2.
Viewing angle
The angel is very wide.
3.
Haze
The haze is very little, almost can not be made out by human eyes. 4.
Driving voltage
The driving voltage is very low to be good for safety.
5.
Thermal stability
There is no change while being touched by hand or heated by sunlight. 6.
Uniformity
Very uniformity due to new thermos-curing technology and
high-precision producing technology.
7.
Adhesion strength
The adhesive strength between crystal layer and ITO is uniformity and balance and very strong, never delamination due to surface treatment technology.

8.
Operational lifetime
Much prolonged. More than 100 million switch.

9.
UV stability without other protection
It’s till good after tested under UV radiation for 1 month. The UV-RESISTANCE is high strengthened.
10
Moisture resistance
It’s can stay good in non-sealing condition. Very good moisture resistance make it easier for storage and installation.

ALL RIGHT RESERVED BY:
(Product 1. )Ethylene-Vinyl Acetate EVA Interlayer Film for Safety Laminated Glass
(Product 2.) China Solar EVA Film for Solar Panel Encapsulation (Product 3.) China Smart Switchable Film for Privacy Glass, Smart Glass www.evafilms.com / www.cncnext.com
[email protected]/ [email protected] / [email protected] /[email protected]

Storage of Smart Glass Film(switchable glass film, privacy glass film)

When in long time storage of smart glass film(switchable glass film, privacy glass film)
, because the smart glass film is made of liquid crystal and polymer, so the smart glass film(switchable glass film, privacy glass film) may be decompound by the acid and basicity in the air.

But CNC INTERLAYER TECH use the highest purity of crystal to avoid decompounding.

But anyway, if you don’t use the smart glass film(especially the non-adhesive smart glass film), please repack it in sealed condition.

All rights reserved by CNC-INTERLAYER TECH:
【Product 1】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS 【Product 2】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS 【Product 3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS Web: www.CNCnext.com www.HelloGlass.com
Mail: [email protected]
[email protected]/
[email protected]

Properties of CNC SPD Self-adhesive Smart Film for Privacy Glass www.evafilms.com www.HelloGlass.com

CNC SPD Self-adhesive Smart Film owns-Best electric-optical
properties, highest transparency in clear state, and highest scattering (privacy ability) in power device off state.
CNC SPD Self-adhesive Smart Film owns-Good stability and Widest range for driving voltage.
CNC SPD Self-adhesive Smart Film owns-Best UV blocking and UV stability CNC SPD Self-adhesive Smart Film owns-Super water/humidity resistance properties
CNC SPD Self-adhesive Smart Film owns-Widest range for application environment temperature
CNC SPD Self-adhesive Smart Film owns-Ultra adhesive strength inside PDLC Film(liquid crystal, polymer, ITO, PET), no delamination possibility
CNC SPD Self-adhesive Smart Film owns-With patented ITO coating technology CNC SPD Self-adhesive Smart Film owns-Operational lifetime is highly prolonged,

All rights reserved by CNC-INTERLAYER TECH:
【Product 1】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS 【Product 2】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS 【Product 3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS Web: www.CNCnext.com www.HelloGlass.com
Mail: [email protected]
[email protected]/
[email protected]

Properties of CNC SPD Self-adhesive Smart Film for Privacy Glass.pdf

Power Device for Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film)
www.SmartestGlass.com www.EVAfilm.com

Power Device for Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film) (1)

Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film) need power device to transform the voltage.
When if you want to make smart glass, you will need power device for Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film).
Here are some notes you should know when you want to purchase power device for smart glass.

1-How many square meters of Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film) you would like to power?
Some power device can power 5 square meters Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film).
Some power device can power 10 square meters Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film).
Some power device can power 15square meters of Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film).
So, please make sure how many square meters of Smart Glass Film(Magic Film, PDLC Film, SPD Glass Film) you want to power on.

2-Local voltage in your please, is it 110v or 220v?
You need to tell the smart glass film manufacturer when you buy the power device for smart glass film.

3- Following are some examples of the technical data of power device:
Power Device for Self Adhesive Smart Glass Film
AC-AC ADAPTOR
TRANSFORMER
INPUT:120VAC 60HZ 1A
OUTPUT:65VAC 1A
Power Device for Self Adhesive Smart Glass Film
AC-AC ADAPTOR
TRANSFORMER
INPUT:220VAC 60HZ 1A
OUTPUT:65VAC 1A








All rights reserved by CNC-INTERLAYER TECH:
【Product 1】CNC-Force® EVA INERLAYER FOR ARCHITECTURAL LAMINATED GLASS
【Product 2】CNC-Smart® SMART FILM FOR PRIVACY SWITCHABLE GLASS
【Product 3】CNC-Shield® PVB INTERLAYER FOR AUTOMOTIVE WINDSHIELD GLASS
Web: www.CNCnext.com www.HelloGlass.com
Mail: [email protected]
[email protected]/
[email protected]
